Tail lights to OEM bags? - Suzuki Volusia Forums : Intruder Volusia and Boulevard Forum

Reply

LinkBack Thread Tools
Old 11-18-2012, 11:02 PM   #1 (permalink)
Senior VR Member

Join Date: Oct 2012
Posts: 798
Thanks: 174
Thanked 103 Times in 91 Posts
Garage
Default Tail lights to OEM bags?

Anyone ever add tail lights to their OEM saddle bags? I'd like to increase the bikes visibility. I've been thinking of something like this but not sure how they'd look plus they are a little pricey. If anyone has done such a mod some pics would be great.

Last edited by C50TinAB; 11-18-2012 at 11:07 PM.
C50TinAB is offline   Reply With Quote
Sponsored Links
Advertisement

Old 11-19-2012, 12:36 PM   #2 (permalink)
Junior Member

Join Date: Aug 2012
Location: Carol Stream, IL
Posts: 17
Thanks: 6
Thanked 1 Time in 1 Post
Default

I'm thinking about the exact same project while I've got the bags off for the winter. Would love to do an LED run-brake-turn combo if possible. If anyone could post a link to a similar project with wiring placement ideas it would be GREATLY appreciated! Thanks!
__________________
2005 C50
anthony001 is offline   Reply With Quote
Old 11-19-2012, 01:38 PM   #3 (permalink)
Senior VR Member

Join Date: Oct 2012
Posts: 798
Thanks: 174
Thanked 103 Times in 91 Posts
Garage
Default

Finding one that fits without distorting the leather and reasonably priced is my biggest issue. I just went out the garage and took a measurement and it seems a 4" would be the largest I could go with. So far this 3" round is the best fit although a tear drop shape would match the fender lamp better. The one I linked above will be too large. For myself I only want the bag lights to be a brake and running light. I'll keep the amber turn signals as is.
C50TinAB is offline   Reply With Quote
Old 11-19-2012, 07:45 PM   #4 (permalink)
Super Moderator


Join Date: Dec 2007
Location: Northern Catskill Mountains, New York State
Posts: 6,288
Thanks: 1,879
Thanked 1,741 Times in 1,038 Posts
Default

Member DCinCT added lights to his soft (non-oem) bags this summer. I am sure the steps he took would work fine on the OEM bags, too. Shoot him a PM, if he doesn't weight in here himself in a spell.

.
__________________
Woodswoman
(a/k/a Mrs. BearBait)

2010 Victory Cross Roads, "Doctor Pepper" << FOR SALE http://www.volusiariders.com/51-bike...oss-roads.html
2014 Honda CTX700ND, "Flicker"

Woodswoman is offline   Reply With Quote
The Following User Says Thank You to Woodswoman For This Useful Post:
C50TinAB (11-21-2012)
Old 11-19-2012, 08:31 PM   #5 (permalink)
Senior VR Member

Join Date: Jul 2011
Location: Port Charlotte Fl
Posts: 1,699
Thanks: 51
Thanked 278 Times in 216 Posts
Default

Try this.
__________________
I know you believe that you understand what you think I said but I'm sure you realize that what you heard is not what I meant.

'05 Honda VTX 1300R Champion trike Kit. Mustang Seats and Backrests, K & N Filter, Kuryakyn ISO grips, pegs, floorboards, shifter and brake peddles, Cup Holder. Universal passenger arm rests, Wolo horn, Vista Cruise, Shark 600 watt stereo, ShowChrome Risers, lots of chrome.

http://www.break.com/video/ugc/keywasted-1912477

Last edited by cavie; 08-12-2013 at 06:55 PM.
cavie is offline   Reply With Quote
The Following User Says Thank You to cavie For This Useful Post:
C50TinAB (11-21-2012)
Old 11-21-2012, 12:56 PM   #6 (permalink)
Senior VR Member

Join Date: Oct 2012
Posts: 798
Thanks: 174
Thanked 103 Times in 91 Posts
Garage
Default

Quote:
Originally Posted by cavie View Post
Try this.
Looks like a nice clean install and thanks for the suggestion but it wouldn't work on my bike unfortunately.
C50TinAB is offline   Reply With Quote
Old 11-21-2012, 02:34 PM   #7 (permalink)
Senior VR Member

Join Date: Aug 2009
Location: NC, Raleigh
Posts: 1,342
Thanks: 74
Thanked 89 Times in 84 Posts
Garage
Default

I wanted to do the same kind of thing, and decided to build my own set of LED lights. I found a six-inch strip of 12v red LED's for about $3 and used some aluminum channel from a home store as the frame. I drilled two holes in one side of the channel and inserted some screws from the inside of the channel. I then glued the lights into the channel pieces that I had cut down to match the length of the LED's. I used clear silicone to glue the lights down, they seem to be holding fine. I then drilled two holes into the inner plastic side of the OEM bags and attached the nuts using some thread locker. I ran the wiring from under the seat, following the OEM wiring harness along the inside of the fender and attaching with some nylon wire ties. I thought about wiring into the tail light but I didn't want to disturb the wiring harness which is sealed into a rubber fitting pretty good. I added some black shrink tubing to the LED wires to give them some extra strength and hide them better.

See the attached pics: One is with the brake lights off, one with them on. I have a brake light flasher so they flash with the main brake light. They do not stay on with the running lights. You can purchase small 3" LED strips that can be setup for brake/running lights or brake/turn/running lights if you wish to go that route. My buddy has those on the back of his bags and they look pretty good (sorry no pics). I'm not sure on the cost of those, but if you're interested let me know and I'll follow up and try to get some pics.
Attached Images
File Type: jpg IMG_0927.jpg (270.4 KB, 39 views)
File Type: jpg IMG_0928.jpg (271.9 KB, 40 views)
__________________

2007 black C50T (current) - PGR Member
1973 HD Sportster (sold 2009 - sigh...)
1972 Kawasaki (first bike)

My Gallery
bipestuff is offline   Reply With Quote
The Following User Says Thank You to bipestuff For This Useful Post:
C50TinAB (11-21-2012)
Old 11-21-2012, 03:02 PM   #8 (permalink)
Senior VR Member

Join Date: Oct 2012
Posts: 798
Thanks: 174
Thanked 103 Times in 91 Posts
Garage
Default

Quote:
Originally Posted by bipestuff View Post
I wanted to do the same kind of thing, and decided to build my own set of LED lights.
Building your own is neat idea. I'll keep that in mind. Thanks.
C50TinAB is offline   Reply With Quote
Old 11-21-2012, 04:26 PM   #9 (permalink)
Senior VR Member

Join Date: Oct 2006
Location: South Hamilton, MA
Posts: 343
Thanks: 51
Thanked 38 Times in 28 Posts
Default Reflectors

While it would be nice to do lights, easier is reflectors.

True Value has some that are like a long race track and are easy to put on.

I make a hole in the back of the bag, and use pop rivets to attach the reflectors.

Be good

Richard
rboroff is offline   Reply With Quote
Old 11-21-2012, 06:16 PM   #10 (permalink)
Senior VR Member


Join Date: Oct 2004
Location: Ct,Columbia
Posts: 10,933
Thanks: 1,014
Thanked 2,023 Times in 1,250 Posts
Default

did just what you are asking about this past summer...



lights were given to me by a member here and after much debate as to how they should be mounted...


need an opinion...

initial post had pictures of the lites taped onto bags for mounted look...sorry they are no longer displayed..did some photobucket housecleaning recently but there is some mechanical answers in the thread and suggestions from other members on how to install. Hope it helps.

the end result was what you see...

had another friend/member from here do the electrical...adhering lites to the bags before electrical hookup was very simple...just drilling 2 holes in each bag...because rear lite/brakelite and signal lite are not leds...lights just work as running lites and not blinking signal lite. They are very bright and am very pleased with the look and performance.
__________________
Whats the big hurry...slow down and enjoy the ride!


Last edited by DCinCT; 11-21-2012 at 06:18 PM.
DCinCT is offline   Reply With Quote
The Following 2 Users Say Thank You to DCinCT For This Useful Post:
anthony001 (01-11-2013), C50TinAB (11-21-2012)
